Falcon Pro

Dual-Hall twist throttle for the Falcon Pro.

Closed-end grips. Sold only as a left and right pair.

Closed-end grips. Sold only as a left and right pair.

Horn and ride-mode handlebar switch.

High/low beam headlight. Includes 2 M5×14 304 stainless combination screws.

Color screen display.

43 × 27 × 2.5 mm. Includes mounting screws.

Left lever master cylinder with power-cut switch wire and 1470 mm brake hose.

203 mm diameter, 2.3 mm thick, 54 mm mounting spacing. Includes T30×12 rotor screws and 6 M6 screws.

Includes brake power-cut switch wire. Hose not included.

Titan brand brake lever.

Fits front or rear. Hose not included.

Caliper brake pads, front or rear.

Right lever master cylinder with power-cut switch wire and 1030 mm brake hose.

203 mm diameter, 2.3 mm thick, 44 mm mounting spacing. Includes T25×10 rotor screws and 6 M5 screws.

220 mm diameter, 2.3 mm thick, 44 mm mounting spacing. Includes T25×10 rotor screws and 6 M5 screws.

Includes brake power-cut switch wire. Hose not included.

Mounts the headlight under the handlebar stem.

Ø18 × 11 mm inner bar-end plug.

Ø31.8 mm clamp, 25 mm rise, 8° back sweep, 5° up sweep, 760 mm wide. Sandblasted black anodized 6061-T6 aluminum, laser engraved.

M6×4 direct-mount stem, Ø31.8 mm bar clamp, 50 mm long. Sandblasted black anodized 6061-T6 aluminum.

Inverted fork. 237.5 mm straight steerer, 110 mm hub spacing, Ø20 mm axle, 203 mm travel, 750 mm overall length, 60 lb spring.

Upper clamp for the FAST front fork.

Lower clamp and stem for the FAST front fork.

Includes 2 axle screws.

Sold individually.

Cable guide ring for the fork leg.

Rubber bumper. Sold individually.

Plastic fork leg guard.

Plastic fork leg guard.

Brake-disc side, preload side.

Damping side.

19" × 1.4 rim with 70/100-19 tire and inner tube.

19" × 1.4 matte black aluminum alloy. Includes left and right wheel spacers.

70/100-19 off-road tire.

70/100-19 inner tube.

Heavy-duty rim strip, 19" × 30 mm, red, 1440 mm circumference.

Fork-mounted front fender.

Plastic front number plate.

Ø49 mm, M6×10 thread.

7.5 × 195 × 1.3 mm.

72V 35Ah lithium-ion, CAN-bus communication, LG M50LT cells, 20S7P, black anodized case.

Pro 2.0 controller for the 4T8 main power wiring.

104.2 × 78.8 × 19.9 mm.

Controls the bike's lighting and accessory circuits.

Pendulum-type tip sensor. Cuts power past 65° with a 1-second delay.

72V to 12V, 6A.

Main power lead from the battery to the controller (no breaker version).

Steel plate inside the frame that separates the battery from the outside. Q235 steel.

Steel plate inside the frame that separates the battery from the outside. Q235 steel.

Steel tray that supports the battery from below. Q235 steel.

Mounts the tip-over sensor to the battery base frame. Q235 steel.

Plastic cover under the battery.

Plastic pads on the front and rear battery partition plates.

85 × 85 × 10 mm foam for the battery partition plates.

48 × 23 × 1 mm.

691.2 × 211.8 × 436.4 mm. Not sold separately at retail.

Protective plate for the motor. Q235 steel.

Plastic battery compartment cover.

Carbon fiber battery compartment cover.

Aluminum alloy side stand.

Aluminum block that mounts the left foot peg and kickstand.

Aluminum block that mounts the right foot peg.

Complete set with bracket, pin and nut.

Complete set with bracket, pin and nut.

12V 1.5A, 105 dB, CE certified. Includes M6×10 mounting screw.

Plastic cover for the ignition lock.

Ignition switch and battery compartment lock with keys.

Plastic liner inside the frame that keeps the battery off the frame and routes wiring.

Plastic liner inside the frame that keeps the battery off the frame.

Steering head bearing set.

Steel brace between the left and right foot peg mounts.

Steel, Ø13 × 43.4 mm.

Steel, Ø13 × 29.3 mm.

Steel return spring for the kickstand.

Latch on the battery compartment cover.

Ø6.5 × 27.5 mm.

Ø10 × M8 × 31 mm. Includes flanged lock nut.

Magnetic switch that detects when the kickstand is down or up.

30 × 15 × 8 mm with 3M adhesive backing.

Model CC-1.

Complete 4T8 main wiring harness for the Pro 2.0 (also used on the GT).

Bracket that holds the seat cushion.

Seat cushion for the seat subframe.

Seat cushion for the seat subframe.

Plastic fender behind the seat.

Plastic trim under the seat. Includes 8 plastic push rivets.

12V 0.6W tail light.

Plastic plate mounted between the tail light bracket and tail light.

Plastic trim over the battery compartment lock.

Plastic trim over the battery compartment lock.

Q235 steel bracket for the tail light.

80 × 7 × 4 mm, 60° hardness, 3M adhesive backing.

5-pin extension cable for the tail light.

79motor. 5,000W rated, 8,500W peak.

Left-side plastic motor cover.

Left-side carbon fiber motor cover.

Ø73 × 6.9 mm decorative cap.

51-tooth large belt pulley on the jackshaft.

HTD 560-8M-20 belt.

Sandblasted black anodized 6061 aluminum with 5 bearings.

420 chain, 14 teeth.

Gold O-ring chain. Use with 14T front and 48T rear sprockets.

Ø8.1 × Ø18 × 23.5 mm.

Ø8.1 × Ø18 × 20.5 mm.

44.5 × 48.6 × 3 mm.

Ø12 × Ø17 × 13 mm.

Ø12 × Ø17 × 16.5 mm.

Ø12 × Ø20 × 9 mm.

Rear swingarm that holds the rear wheel.

Spring with gas reservoir, 450 lb spring, adjustable compression and rebound, 85 mm stroke, 265 mm overall length, 26 mm top / 24 mm bottom eye width.

Reinforced triangle linkage mounted on the frame.

Links the rear shock to the swingarm and frame.

Mudguard mounted on the swingarm.

Plastic cover over the jackshaft that keeps out debris and stops rattles.

Plastic chain guard cover.

Carbon fiber chain guard cover.

Caliper bracket for a 203 mm rear disc.

19" × 1.4 rim with 70/100-19 tire and inner tube.

19" × 1.4 matte black aluminum alloy.

420 chain, 48 teeth.

Fits inside the triangle-link bearing. Ø8.1 × Ø12 × 19 mm.

Fits inside the three-hole linkage bearing. Ø8.1 × Ø12 × 32 mm.

7075 aluminum sliders on each side of the swingarm for chain adjustment.

Steel bushing on the brake-disc side of the rear hub.

Steel bushing on the sprocket side of the rear hub.

33.2 × 29.4 × 14.9 mm.

Replacement key head.

72V 10A battery charger with export power cord.

72V 10A battery charger with China-standard power cord.
